Google Earth Engine (GEE)

Google Earth Engine (GEE) is a cloud-based Geographic Information System (GIS) and remote sensing platform developed by Google that enables the analysis of planetary-scale environmental data. GEE provides advanced computational infrastructure for monitoring, modeling, and analyzing environmental data over time such as surface temperature vegetation cover land use and water presence. By utilizing data derived from satellite imagery it offers a wide range of applications including land classification disaster detection and natural resource management. GEE is accessible to users through JavaScript and Python APIs and provides instantaneous and archival access to hundreds of datasets on the platform.

Google Earth Engine Code Editor (Google Earth Engine)

Core Components of the Platform

Google Earth Engine is an integrated system composed of three core components: a data catalog an analysis infrastructure and developer interfaces.

Data Catalog

GEE provides users with data from various satellite sensors including key remote sensing datasets such as the Landsat series (1972-present) Sentinel-1 and Sentinel-2 MODIS and CHIRPS and SRTM. Additionally the system includes climate topography population and land use data. These datasets are regularly updated and stored in massive volumes.

Analysis Infrastructure

GEE’s cloud-based computational infrastructure allows users to analyze very large datasets without downloading them to their local computers. For example a user can compute 20-year average NDVI values across the entire African continent in seconds. This infrastructure is particularly well suited for tracking environmental change time series analysis and spatial classification.

Developer Interfaces

GEE offers an interactive JavaScript-based code editor and a Python API. The JavaScript interface is commonly used for visual analysis and web-based presentations while the Python API is preferred for scientific research data science projects and automated analyses.

GEE data catalog example of global climate data (Earth Engine Data Catalog)

GEE data catalog example of surface temperature data (Earth Engine Data Catalog)

Application Areas

Google Earth Engine has diverse applications spanning numerous disciplines.

Forestry and Natural Environment Management

In forestry GEE is used to monitor deforestation forest degradation and reforestation processes. International initiatives such as Global Forest Watch utilize this platform to track forest loss in near real time.

Agriculture and Crop Yield Estimation

Vegetation indices such as NDVI and EVI can be calculated via GEE to monitor agricultural production identify cultivated areas and predict harvest yields. These analyses are used by both public institutions and private agricultural technology firms.

Water Resource Monitoring

Temporal and spatial changes in surface water can be analyzed using Sentinel-1 and MODIS data. Parameters such as water scarcity evaporation and groundwater levels can also be studied.

Disaster Risk Management

GEE is frequently used to map post-disaster damage from events such as fires floods and earthquakes. For example after the February 6 2023 earthquake in Türkiye Sentinel-1 data were used to analyze ground subsidence and uplift in the affected region.

Urban Development and Planning

Temporal analysis of urban expansion changes in green spaces and urban sprawl patterns can be studied using Google Earth Engine. This provides urban planners with scientific data to support decision-making.

Temporal analysis study using Google Earth Engine (Sofia L. Ermida)

Advantages and Disadvantages

Advantages

• Superior performance in analyzing very large datasets
• Access to extensive archives and diverse data sources
• Cross-platform API support
• Ease of visualization and online sharing capabilities

Disadvantages

• Requires programming knowledge and presents a learning curve for beginners
• Licensing restrictions on some high-resolution datasets
• Need for data preprocessing such as cloud masking
