Passive Radar

Passive radar systems are a type of radar that detect and track targets by listening to signals emitted by environmental sources, without actively transmitting electromagnetic signals. A sub-application of these systems is Bearing Only Tracking (BOT), a method designed to track targets using only directional (azimuth) information and preferred especially in low-observable (stealth) operations. Due to its ability to monitor targets without emitting active signals, BOT holds critical importance in both military and defense industry applications.

The concept of passive radar first emerged theoretically during World War II in the United Kingdom, where radio broadcasts were monitored to detect aircraft. With technological advancements, BOT techniques became practically feasible from the 1970s onward, thanks to more sophisticated sensor systems and signal processing algorithms. In the 2000s, the development of electronic warfare systems made direction-based passive tracking both more necessary and more achievable.

In the Bearing Only Tracking method, the sensor measures only the direction (azimuth angle) of received electromagnetic signals without transmitting any signal toward the target. These directional measurements are recorded over time and used to estimate the target’s position, velocity, and other dynamic parameters.

1. Measurement: The azimuth direction of the target is determined at each time interval.
2. Filtering: Measurements are typically processed using algorithms such as the Extended Kalman Filter (EKF), Unscented Kalman Filter (UKF), or Particle Filter (PF).
3. Estimation: The target’s trajectory is estimated based on the time-varying directional measurements.

• Single Sensor BOT: Requires long-term measurements; maneuvering behavior of the target is inferred from observed data.
• Multi-Sensor BOT (Passive Multistatic Radar): Simultaneous azimuth measurements from multiple stations allow more precise determination of target position. Triangulation is the primary method used.

^{Passive Radar (}MilitaryEmbedded⁾

• Military Defense Systems: Tracking air, sea, and ground targets without being detected by enemy radar systems.
• Electronic Warfare: Enables intelligence gathering without radar detection, due to low power consumption and low electromagnetic visibility.
• Air Traffic Control: Ensures flight safety in areas or scenarios where active radar signals cannot be transmitted.
• Unmanned Aerial Vehicle (UAV) Applications: An ideal solution due to advantages in low weight and low energy requirements.

• Does not emit electromagnetic signatures, making it difficult for enemy radar systems to detect (stealth compatible).
• Consumes significantly less energy than active radar systems.
• Can be deployed at lower cost due to its simpler architecture.
• Offers potential for multi-target tracking through advanced signal processing techniques.
• Can be more robust in complex environments such as noisy or electronically jammed conditions.

• Only azimuth information is available, making it difficult to determine the exact target position; position estimation requires time and multiple measurements.
• Tracking accuracy decreases for maneuvering targets, and performance may degrade in high-dynamic scenarios.
• Requires continuous and prolonged observation for effective tracking.
• High accuracy often necessitates multi-sensor integration (sensor fusion).
• Noise and signal interference can negatively affect azimuth measurements.

• AI-Assisted Tracking: Deep learning-based algorithms improve target estimation accuracy by leveraging directional data.
• RF Spectrum Density Analysis: Advanced signal processing techniques enable the separation of target signals from multiple competing sources.
• Quantum Radar and New Sensors: Passive tracking systems are becoming capable of more precise measurements through integration with quantum technologies.
