Human-Machine Interface

Human-Machine Interface is an interface system composed of software and hardware components that enable information exchange and control interaction between an operator and industrial systems. In industrial environments, this interface is implemented through operator panels, allowing direct interaction with production lines, machines, and automation infrastructure. The Human-Machine Interface enables monitoring and control of system states by processing multidimensional and high-volume data collected from the field. This data is presented in graphical, intuitive, and functional formats to support the operator’s decision-making processes.

These systems are primarily used in production facilities to enhance process efficiency, safety, and traceability. Through HMI screens, operators can view schematics representing the system’s operational status, monitor process parameters, and make adjustments as needed. Additionally, operations such as starting pumps, modifying temperature or pressure values, reviewing error messages, and managing alarms can all be performed via this interface.

Modern HMI panels support operators in their decision-making processes through features such as touchscreens, data trend graphs, remote access capabilities, and advanced alarm management systems. As a result, production continuity is maintained and rapid intervention becomes possible in the event of potential failures.

Fundamental Concepts and Functionality

The Human-Machine Interface (HMI) is a hardware and software-based system that enables an operator to communicate with the control unit of an industrial system, typically a Programmable Logic Controller (PLC). This architecture is designed to facilitate effective and safe human-machine interaction in production lines, energy facilities, process control systems, and automation infrastructures.

The primary function of an HMI is to transform complex technical data collected from the field into meaningful, accessible, and manageable information for the operator. This allows the operator to monitor the system’s current state, evaluate process variables, and directly control the production process. This visualization enhances the operator’s understanding of system dynamics, enables rapid fault detection, and contributes to process optimization.

Interaction with HMI panels typically occurs through touchscreens; however, in certain industrial applications, physical keypads, function keys, or external keyboards may also be used. This variety has been developed to meet ergonomic and safety requirements under different operating conditions. Additionally, HMI systems facilitate intuitive operation of machine functions by allowing operators to monitor input and output parameters, control production steps, and intervene when necessary.

Comparison of HMI and Industrial PC (IPC)

In industrial environments, both Human-Machine Interfaces (HMI) and Industrial Personal Computers (IPC) are widely used for data collection, processing, and visualization. Although both devices share similar external designs, they differ significantly in functionality, performance, flexibility, and cost.

HMI Operator Panels

HMI operator panels are specialized hardware devices designed for specific control and visualization tasks and are typically used to communicate with a Programmable Logic Controller (PLC). These panels function as system components that monitor the PLC’s operational status and provide a visual interface to the user.

The core function of HMIs is to exchange data with the PLC via a predefined communication protocol. Early-generation HMIs typically operated using serial protocols such as MODBUS RTU and PROFIBUS, while modern systems now support Ethernet-based protocols such as Modbus TCP, EtherNet/IP, and Profinet. These panels generally run on a closed operating system, which enhances security by preventing the installation of external software and protecting against viruses and malicious code. The processors used in HMIs are optimized solely for efficiently running visualization software, resulting in lower processing power compared to IPCs.

Screen sizes typically range from 4 to 12 inches, although larger models are available to meet industrial requirements. In touchscreen technology, traditional systems use resistive screens, while capacitive touchscreen technology is preferred for supporting swipe, zoom, and multi-touch gestures.

HMIs are usually programmed using proprietary software provided by the manufacturer, and software compatibility is not guaranteed across different brands. This means that when a project must be transferred to another brand, the entire design must be rebuilt from scratch.

Industrial PCs (IPC)

Industrial PCs (IPC) are systems that offer higher performance, scalability, and flexibility compared to traditional HMIs. IPCs can perform multiple tasks simultaneously on a single device—for example, an IPC can function as a logic controller, data acquisition unit, and visualization interface all at once. This integrated structure reduces system costs while improving operational efficiency and processing speed.

Thanks to high processing power, large memory (RAM) capacity, and ample storage space, IPCs can effectively handle data-intensive processes. They typically operate on open operating systems such as Windows. This enables the installation of software from various manufacturers but also increases cybersecurity risks. Therefore, robust antivirus software and hardware-based security measures are essential for IPC systems.

IPC screen sizes are generally larger than those of HMIs, and the devices include multiple connection interfaces such as dual Ethernet ports, multiple USB connections, and serial communication ports. These hardware features simplify the integration of different devices and enhance the system’s adaptability to future industrial applications. In summary, HMIs provide stable, secure, and low-cost solutions for specific and limited tasks, while IPCs offer a more suitable platform for complex industrial systems due to their versatile software support, high processing capacity, and expandable architecture.

Criteria for Selecting Operator Panels

The selection of an appropriate Human-Machine Interface (HMI) panel in industrial applications depends on the system’s functional requirements, operating environment, and operational conditions. Various technical and environmental factors considered during the selection process directly affect the system’s performance, reliability, and lifespan.

Environmental Conditions

The physical environment in which the HMI panel will operate is one of the most critical factors in the selection process. Industrial devices must withstand demanding conditions such as high temperatures, extreme cold, dust, humidity, vibration, or chemical exposure. Therefore, most industrial HMI panels are manufactured from durable materials such as die-cast aluminum or stainless steel and feature high ingress protection ratings such as IP65 or IP66.

For systems operating under harsh conditions, “rugged”-rated models are preferred, while “marine”-certified panels are used for maritime or offshore applications. These models provide additional protection against saltwater, vibration, and continuously humid environments.

Screen Size and Touch Technology

Screen size selection should be based on the distance from which the operator needs to view the data and the level of detail required. Larger screens can display more information and graphics simultaneously, while smaller screens offer easier installation in confined spaces. HMI panels in the industrial market are available with screen sizes ranging from 4 inches to 21 inches.

Touchscreen technology is another critical factor in operator interaction. Traditional resistive screens support single-point touch, while modern projected capacitive (PCAP) screens support multi-touch gestures such as swiping, zooming, and rotating. Additionally, PCAP screens offer higher optical clarity, longer lifespan, and the ability to operate with gloves.

Communication and Integration Capability

The selected HMI panel must support communication protocols compatible with the facility’s Programmable Logic Controllers (PLCs), motion control systems, and other automation components. This compatibility determines the ease of system integration and the continuity of data flow.

Modern HMIs support open standard protocols such as EtherNet/IP, Modbus TCP/IP, Profinet, and OPC UA, enabling manufacturer-independent communication with devices from different vendors. Additionally, the HMI configuration software used must be fully compatible with the PLC brand and version in the system.

Processing Power, Memory, and Storage Capacity

The hardware capability of the panel must be determined according to the complexity of the application to be executed. Operations such as high-resolution graphics, animated process screens, data logging, or rapid screen transitions require advanced processors and sufficient memory capacity.

For example, ARM Cortex-A9 or similar processors ensure performance stability in complex projects. Insufficient memory capacity can lead to screen delays, slow alarm management, and a degraded operator experience. Therefore, processing power and memory size must be planned according to the data intensity of the project.

Software Features and Functionality

HMI panels are programmed using manufacturer-specific design and configuration software. Platforms such as ABB Panel Builder, Beijer iX Developer, or Siemens TIA Portal determine the interface’s appearance and functionality. Pre-built templates, graphic symbol libraries, multi-language support, and alarm management tools significantly accelerate the engineering process.

Some advanced HMI models integrate programming environments compliant with the IEC 61131-3 standard, such as CODESYS. This allows the same device to perform both control and visualization functions, simplifying system architecture and reducing hardware costs. Ultimately, selecting the correct HMI panel requires a comprehensive evaluation of criteria such as environmental conditions, screen technology, communication protocols, hardware capacity, and software compatibility. Careful analysis of these parameters ensures long-lasting, reliable, and efficient operator interaction in industrial automation systems.

Technological Advancements and Modern HMIs

Evolution of HMI Technologies and Next-Generation Applications

Rapid technological advancements have significantly enhanced the functionality, connectivity, and integration capabilities of Human-Machine Interface (HMI) panels. Modern HMI systems have evolved beyond mere visualization and control tools to become intelligent, connected, and data-driven structures aligned with Industry 4.0 vision.

Integrated PLC + HMI Systems

To save space and reduce costs in small and medium-sized machines or modular process units, systems that combine PLC and HMI functions into a single enclosure have been developed. These “all-in-one” integrated solutions shorten installation time, reduce cabling requirements, and simplify system configuration by providing integrated control and visualization functions.

These panels are particularly preferred in applications where field wiring must be minimized, such as compact machines. Since both the control logic and the visual interface operate on the same hardware, data latency is reduced, improving system response speed. This feature provides significant advantages in terms of efficiency and reliability for small production lines and independent process modules.

Industrial Internet of Things (IIoT) and Cloud Integration

Next-generation HMI panels are key components of the Industrial Internet of Things (IIoT) infrastructure. These panels support modern data communication protocols such as MQTT, OPC UA, and AMQP, enabling secure, encrypted, and real-time transfer of field data to cloud-based platforms.

Built-in Wi-Fi, Ethernet, 4G/LTE, or in some models 5G connectivity modules allow HMI panels to support smart manufacturing applications such as remote monitoring, data analytics, performance optimization, and predictive maintenance. These features enhance production continuity and contribute to reduced operational costs.

Moreover, modern HMIs use edge computing capabilities to analyze data collected on-site and transmit only meaningful information to the cloud. This approach reduces network traffic and supports faster decision-making processes.

Virtual and Web-Based HMI Solutions

In industrial automation architectures, virtual and web-based HMI systems are increasingly replacing physical HMI panels. These solutions allow the visualization interface to run on a server or in a cloud environment, enabling operators to access the system via web browsers on devices such as laptops, tablets, or smartphones.

Virtual HMIs offer advantages such as platform-independent access, simplified remote maintenance, and lower hardware costs. This approach provides operational flexibility, particularly in distributed control systems (DCS) or facilities without continuous operator presence.

Additionally, web-based HMI solutions automatically adapt to different screen sizes through HTML5-based interfaces and responsive design. This ensures a consistent user experience on both mobile devices and large screens in control rooms.

Modern HMI technologies represent a transition from traditional panel-centric control concepts to data-centric, networked, and cloud-based architectures. Through PLC integration, IIoT connectivity, and virtual HMI solutions, these panels have become not only operator interaction tools but also fundamental components of intelligent manufacturing ecosystems.

Application Areas and Panel Types

Human-Machine Interface (HMI) panels are produced as product families with varying technical specifications, durability levels, and performance capacities to meet diverse industrial requirements. This variety enables selection of the most suitable panel based on the scale of the application, environmental conditions, and budget constraints.

Basic / Standard Panels (Basic / Standard HMI)

Basic HMI panels are designed for simple automation applications as cost-effective solutions with limited functionality. They typically perform basic visualization, data monitoring, and alarm management tasks. These panels are preferred in applications involving a single PLC and low graphical complexity. They provide an economical and reliable solution for simple control scenarios such as small machines, packaging lines, or HVAC systems.

Advanced Panels (Advanced HMI)

Advanced HMI panels are equipped with high processing power, larger screen sizes, multiple communication ports, and advanced software features. These panels are suitable for visualizing complex production processes or integrated automation systems. Supporting multiple communication protocols such as EtherNet/IP, Modbus TCP/IP, and Profinet, these panels can communicate simultaneously with multiple controllers. Additionally, their high-resolution screens enable detailed process graphics and data trends, supporting operator decision-making.

Rugged Panels (Rugged HMI)

Rugged HMI panels are specifically designed to operate under harsh industrial conditions and are protected against external factors such as dust, water, humidity, vibration, and extreme temperatures. They typically feature casings made of die-cast aluminum, stainless steel, or reinforced polycarbonate and are manufactured with high protection ratings such as IP65/IP66. These panels can be safely used in heavy industrial environments such as mining, petrochemicals, food processing, and steel production. Some models are also available in explosion-proof (ATEX-certified) versions.

Marine Panels (Marine HMI)

Designed for maritime applications, these panels are developed for use in ships, offshore platforms, and port control systems. They hold international maritime certifications such as DNV-GL, Lloyd’s Register, or ABS. Marine HMIs are engineered to withstand environmental challenges such as high humidity, salt-laden air, vibration, and temperature fluctuations. They commonly feature high-brightness screens and day/night modes to ensure readability under varying lighting conditions.

Handheld Panels (Handheld HMI)

Handheld HMI panels are developed for situations where operators must work close to machinery. They are commonly used in robot programming, testing, and maintenance processes. These panels typically operate via wired or wireless connections and are equipped with safety features such as emergency stop (E-Stop) and enable switch. Despite their portable design, they maintain industrial durability and provide flexibility and mobility on production lines.

Control Panels (Control Panels)

Control panels are systems that integrate HMI and PLC functions into a single hardware unit. These panels support control software compliant with the IEC 61131-3 standard, such as CODESYS. Since both logic control and visualization operations can be performed on a single device, they offer advantages in terms of hardware cost and panel space. They are preferred in compact machines, modular systems, and mobile equipment due to ease of installation and simplified maintenance.

Web Panels

Web panels operate as client devices connected to a web server, replacing traditional HMI software. They provide a platform-independent, centralized visualization solution by displaying HTML5-based interfaces. Operators can access the same interface through web browsers (e.g., Chrome, Edge, or Safari) from various devices such as computers, tablets, or smartphones. This structure offers high flexibility for remote maintenance, system monitoring, and data management.

The wide range of HMI panels enables industrial enterprises to develop customized solutions tailored to their specific technical requirements, budgets, and environmental conditions. Basic models serve economical applications, while advanced and rugged models address industrial environments requiring high performance and security. This variety makes it possible for HMI technology to be effectively utilized across all scales of industrial automation.
